Rectangular LED Lighting Connector JST-08R-JWPF-VSLE 8 Way JST JWPF Series

Name: Rectangular LED Lighting Connector JST08RJWPFVSLE 8 Way JST JWPF Series
Brand: YBADDVANCE
Price: 1 USD

Quality Rectangular LED Lighting Connector JST-08R-JWPF-VSLE 8 Way JST JWPF Series wholesale

Brand Name : YBADDVANCE

Model Number : JST-08R-JWPF-VSLE

Certification : ISO9001

Place of Origin : China(mainland)

MOQ : 100 units

Price : Negotiation

Payment Terms : T/T, Western Union,PayPal , credit card

Supply Ability : 50,000 units/moth

Delivery Time : About 5-8 work days

Packaging Details : Inside packing :100 units / lot put into bags.Outside packing :carton 5 layer

P/N : JST-08R-JWPF-VSLE

Way : 8 way

Color : White

Gender : Female

WARRANTY : 1 year

Type : Sealed Connector

Martial : PBT/PA66

HS code : 8536909000

Feature : Waterproof

PLACE OF ORIGIN : Shaanxi,China

Contact Now

JST-08R-JWPF-VSLE 8 Way JST JWPF Series Rectangular LED Lighting Connector

Description

8 Way JST JWPF Series Rectangular LED Lighting Connector

Pitch Spacing : 2mm

Height : 10.7 mm

Length : 16.5 mm

Width : 9.5 mm

IP rating: IPX7

Mating parts: JST-08T-JWPF-VSLE
Operating Temp Range: -55°C to +85°C

Specification

Item name	JST-08R-JWPF-VSLE 8 Way JST JWPF Series Rectangular LED Lighting Connector
P/N	JST-08R-JWPF-VSLE
Wire Size	22-26AWG
Operating Temperature range	-55℃~85℃
Insulation resistance	100M Min.
MOQ	100 units/lot
Key words	8 pin Sealed Connector
Design Tooling	Sending us samples or drawing to design it
Delivery Time	About 5-8 work days
Sealed/Unsealed	sealed
Leak current	Initial50kPa Min.after durability tests30kPa Min.
The number of hole	8 way
Color	White
Warranty	1 year
Application	Automoive Motorcycles

Product Picture Details

Rectangular LED Lighting Connector JST-08R-JWPF-VSLE 8 Way JST JWPF Series
